T/B PLATYTERA

PLATYTERA

PARTICULARS
Vessel Type Anchor Handling, Salvage Tug
IMO Number 9439278
Callsign SVA7933
Port of Registry Piraeus
Year Built 2007
Classification notations Bureau Veritas Hull Mach, Tug, FIFI Capability, Unrestricted navigation
DETAILS
Length Overall 40m
Breadth 11.8 m
GRT-NRT 499/149
Depth Moulded 4.6 m
Maximum draft 3.8 m
Clear deck Space 150 m2
Deck loading 5 t/m2
Max Speed 12 kn / 7 m3
Economical speed 10 kn / 4.2 m3
Bollard Pull 55.9 t
Sewage Plant MARPOL compliant 20 persons
Rudders Twin
Joystick Not fitted
CAPACITY
Fuel Oil 368 m3
Fresh Water 172 m3
Foam 7.8 m3
Detergent 9.3 m3
MACHINERY
Main Engines 2 x Caterpillar 3512B – 1936 BHP each
Generators 2 x Caterpillar 3406C – 307 BHP - 229 kW each
Bow Thruster 1 x 220 kW HRP 3001TT
Propulsion 2 x Fixed pitch
ACCOMMODATION
Berths 2x 1, 2x 2, 1x 4, 2x4
Total 18
FIRE FIGHTING
Class FIFI Capability
Monitors 2 x 600 m3/hr
Pumps 1 x 1200 m3/hr
DECK EQUIPMENT
Towing Winch
Type Double drum waterfall
Pull 50 t
Wire Capacity 1000 m x 48 mm
Anchor Handling Winch
Type Plimsol double drum waterfall
Pull 50 t
Brake Holding 120 t
Wire Capacity 1000 m x 48 mm
Tugger Winch
Number & Capacity 2 x 5 t SWL
Wire Capacity 100 m x 26 mm
Other Deck Equipment
Towing Pins Plimsoll 100 t
Stern Roller Plimsoll 1.45 m x 3.5 m, 150 t SWL
Shark Jaws 100 t Strong Jaw, 78 mm
Deck crane 2T @ 6m Fixed Boom
LIFESAVING
Liferafts 4 x 18 man
Lifejackets 28
FRC/Rescue Boat/Davit Narwhal SV420
Lifebuoys 8
SPECIALIST
Rescue Zone Fitted
SALVAGE/ ANTIPOLLUTION
Oil Spill Response booms Yes
Salvage pumps Yes
